Specifications

• Dimensions

  add remove
  • Length:
    94.9 in
  • Overall width:
    36.6 in
  • Overall height:
    50.0 in
  • Seat height, unladen:
    26.5 in
  • Rake (steering head):
    30
  • Trail:
    5.8 in
  • Wheelbase:
    64.2 in
  • Tires, front specifications:
    130/90B16,73H,BW
  • Tires, rear specifications:
    150/80B16,77H,BW
  • Fuel Capacity:
    5.0 gal
  • Weight, as shipped:
    657 lbs
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 117 Classic
  • Bore:
    4.1 in
  • Stroke:
    4.5 in
  • Displacement:
    117 cu in
  • Compression ratio:
    10.3:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-1; catalyst in header
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    120.2 ft-lb
  • Engine torque (RPM):
    2,500
  • Horsepower:
    98 HP / 73 kW @ 4600 rpm
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    47 mpg (5 l/100 km)
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
  • Final drive:
    Belt, 32/66 ratio
• Chassis

  add remove
  • Front fork:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
  • Wheels, front type:
    Black Tubeless Laced w/ 36 Bright Spokes
  • Wheels, rear type:
    Black Tubeless Laced w/ 36 Bright Spokes
  • Brakes, type:
    Solid, uniform expansion rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), Headlamp:
    All LED, low beam, high beam and signature position lamp
  • Lights (as per country regulation), Tail/Stop:
    LED Buffett tail lamp
  • Lights, front signal lights:
    LED Bullet Turn Signals
  • Lights, rear turn signals:
    LED bullet light bar
  • Gauges:
    5-inch (127 mm) analog speedometer with digital gear, odometer, fuel level, ride modes, heated gear, traction control, ABS, TPMS, cruise control, clock, trip, range and tachometer indication
  • Battery:
    Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F
  • Charging:
    Three-phase, 48 Amp system (364 Watts @13 Volts, 900 rpm, 624 Watts max power @ 13 Volts, 2000 rpm)
  • Starting:
    1.6 kW electric with solenoid shift starter motor engagement
  • Auxiliary lamps:
    LED fog
  • Electric power outlet:
    USB C-Type , Output 5V at 2.4 Amp
