Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    72.2
  • Torque (Nm):
    97.7
  • Valves:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Displacement (cc):
    1130.7
  • Compression Ratio:
    9.5:1
  • Torque RPM:
    5900
  • Fuel Injector Size (mm):
    60
  • Horsepower (bhp):
    100
• TRANSMISSION

  add remove
  • Number Of Speeds:
    6
  • Gear Ratio (1):
    10.78
  • Gear Ratio (2):
    7.33
  • Gear Ratio (3):
    5.84
  • Gear Ratio (4):
    4.96
  • Gear Ratio (5):
    4.38
  • Gear Ratio (6):
    4.03
  • Final Drive Ratio:
    2.36
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    91
  • Width (in):
    34.6
  • Height (in):
    47.5
  • Wheelbase (in):
    61.5
  • Dry Weight (lbs):
    538
  • Wet Weight (lbs):
    558
  • GVWR (lbs):
    988
  • Fuel Capacity (gal):
    3.3
  • Engine Displacement to Weight (cc):
    2.1
  • Ground Clearance (in):
    5.3
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    130/90 - 16 72H
  • Rear Tire (Full Spec):
    150/80 - 16 71H
